On-Screen Display
Setting Up the OSD
Panasonic Semiconductor Development Company
MN102H75K/F75K/85K/F85K LSI User Manual
188
Panasonic
■
Character sizes
The settings shown are for interlaced displays. In progressive displays, the vertical size settings (CVSZ[1:0]) are as follows:
01 = 1x, 10 = 2x, and 11 = 3x. The 00 setting is reserved. In addition, in closed-caption mode, only the b’00’, b’01’, and b’11’
settings are available for CVSZ[1:0]. The b’10’ setting is reserved.
Figure 7-28 Character Size Combinations
b'00'
b'01'
b'10'
b'11'
b'00'
b'01'
b'10'
b'11'
Ч
1
Ч
2
Ч
3
Ч
4
Ч
1
Ч
2
Ч
6
Ч
4
CVSZ[1:0]
CHSZ[1:0]
16
32
48
64
18
36
72
108
