On-Screen Display
OSD Registers
MN102H75K/F75K/85K/F85K LSI User Manual
Panasonic Semiconductor Development Company
211
Panasonic
VSHT1: Vertical Shutter 1 Register
x’007F22’
VSON1: Vertical shutter 1 on/off
0: Off
1: On
VSP1: Vertical shutter 1 shuttering direction
0: Shutter below
1: Shutter above
VSMP1: Vertical shutter 1 movement direction
0: Top to bottom
1: Bottom to top
VSM1: Vertical shutter 1 movement control
0: Don’t move
1: Move
VST1[9:0]: Vertical shutter 1 position
HSHT0: Horizontal Shutter 0 Register
x’007F24’
HSON0: Horizontal shutter 0 on/off
0: Off
1: On
HSP0: Horizontal shutter 0 shuttering direction
0: Shutter to the right
1: Shutter to the left
HSMP0: Horizontal shutter 0 movement direction
0: Left to right
1: Right to left
HSM0: Horizontal shutter 0 movement control
0: Don’t move
1: Move
HST0[9:0]: Horizontal shutter 0 position
Bit:
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
—
—
VSON
1
VSP1
VSMP
1
VSM1
VST1
9
VST1
8
VST1
7
VST1
6
VST1
5
VST1
4
VST1
3
VST1
2
VST1
1
VST1
0
Reset:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
R/W:
R
R
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Bit:
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
—
—
HSON
0
HSP0
HSMP
0
HSM0
HST0
9
HST0
8
HST0
7
HST0
6
HST0
5
HST0
4
HST0
3
HST0
2
HST0
1
HST0
0
Reset:
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
R/W:
R
R
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
