9 EN
Preparations
Basic section
Application section
Knowledge section
Speaker cord (Red line)
Speaker (Left)
AC POWER cord
To AC wall outlet
System connections
Microphone for Room Equalizer
(not for recording)
AC POWER cord
To AC wall outlet
How to connect the speaker cords
Speaker cord for
surround (Blue line)
Audio cord
Audio cord
− + − + − + − +
− + − + − + − +
1 2 3 4
LS-AXD7 L
÷ When subwoofer, center, and the two surround terminals are connected to the 3.1 channel speaker system to be sold later,
expansion to a 5.1 channel system is possible. For details, please refer to the operation instructions for your equipment.
Connect this only for setting the
auto room equalizer, and keep it
disconnected at other times.
System control
cord
C-AX7
M-AX7
