KTM 690 ENDURO EU - Manual (Page 158)

TECHNICAL DATA - ENGINE TIGHTENING TORQUES
156
Screw, cylinder head M10 Tightening sequence:
Tighten diagonally, beginning
with the rear screw on the
chain shaft.
Step 1
15 Nm (11.1 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
45 Nm (33.2 lbf ft)
Step 4
60 Nm (44.3 lbf ft) lubricated with engine oil
Spark plug M12x1,25 17 Nm (12.5 lbf ft) –
Coolant temperature sensor on cylinder
head M12x1.5 12 Nm (8.9 lbf ft) –
Oil drain plug with magnet M12x1,5 20 Nm (14.8 lbf ft) –
Oil pressure regulator valve plug M12x1.5 20 Nm (14.8 lbf ft) –
Plug, oil bore M14x1,5 15 Nm (11.1 lbf ft) Loctite ® 243™
Engine case stud M16x1.5 25 Nm (18.4 lbf ft) Loctite ® 243™
Ignition rotor nut M18x1,5 100 Nm (73.8 lbf ft) –
Nut, engine sprocket M20x1,5 60 Nm (44.3 lbf ft) Loctite ® 243™
Nut, inner clutch hub M20x1,5 100 Nm (73.8 lbf ft) Loctite ® 243™
Nut, primary gear M20LHx1,5 100 Nm (73.8 lbf ft) Loctite ® 243™
Plug, oil screen M20x1,5 15 Nm (11.1 lbf ft) –
Plug, timing chain tensioner M20x1,5 25 Nm (18.4 lbf ft) –
Screw in generator cover M24x1.5 8 Nm (5.9 lbf ft) –
Plug, oil thermostat M24x1,5 15 Nm (11.1 lbf ft) –
