MAINTENANCE WORK ON CHASSIS AND ENGINE
94
9.41
Fitting front wheel x
Warning
Danger of accidents Reduced braking due to oil or grease on the brake discs.
– Always keep the brake discs free of oil and grease, and clean them with brake cleaner when necessary.
100265-10
– Check parts for damage and wear. Replace damaged or worn parts.
– Clean and grease shaft seal rings
 and bearing surface  of the spacing sleeves.
Long-life grease ( P. 170)
– Fit the spacing sleeves.
100266-10
– Lift the front wheel into the fork, position it, and insert the wheel spindle.
– Mount and tighten screw
 .
Specification
Screw, front wheel spindle M24x1.5 40 Nm (29.5 lbf ft)
– Operate the hand brake lever several times until the brake pads are lying correctly on
the brake disc.
– Remove the motorcycle from the work stand. ( P. 56)
– Pull the front wheel brake and push down hard on the fork several times to align the
fork legs.
