TECHNICAL DATA - CHASSIS TIGHTENING TORQUES
164
Screw, magnetic holder on side stand M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw, voltage regulator/rectifier M6 8 Nm (5.9 lbf ft) –
Screw, SLS valve M6 4 Nm (3 lbf ft) –
Screw, ignition lock M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite ® 243™
Nut, manifold on cylinder head M8 25 Nm (18.4 lbf ft) Copper paste
Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, exhaust clamp on main silencer M8 25 Nm (18.4 lbf ft) –
Screw, front brake caliper M8 25 Nm (18.4 lbf ft) Loctite ® 243™
Screw, main silencer holder M8 25 Nm (18.4 lbf ft) –
Screw, main silencer holder on fuel tank M8 25 Nm (18.4 lbf ft) Loctite ® 243™
Screw, rear footrest bracket M8x16 25 Nm (18.4 lbf ft) –
Screw, front footrest bracket M8 25 Nm (18.4 lbf ft) –
Screw, spring holder on side stand
bracket M8 25 Nm (18.4 lbf ft) Loctite ® 243™
Screw, top triple clamp M8 17 Nm (12.5 lbf ft) –
Screw, bottom triple clamp M8 12 Nm (8.9 lbf ft) –
Screw, fork stub M8 15 Nm (11.1 lbf ft) –
Screw, steering stem M8 20 Nm (14.8 lbf ft) Loctite ® 243™
Screw, handrail M8 20 Nm (14.8 lbf ft) –
Screw, license plate holder, top M8 20 Nm (14.8 lbf ft) –
Screw, fuel tank, top M8 25 Nm (18.4 lbf ft) Loctite ® 243™
Screw, fuel tank, bottom M8 25 Nm (18.4 lbf ft) –
