OPERATING ELEMENTS
26
5.15
Combination instrument - tachometer
100118-10
The tachometer  displays the engine speed in revolutions per minute.
The red marking  shows the excess engine speed range.
5.16
Combination instrument - control lamps
100119-10
The indicator lamps provide additional information on the operating state of the motorcycle.
Possible states
Flashing indicator flashes green in flash rhythm – Flasher light is switched
on.
Idling speed indicator lamp lights up green – Transmission is in neutral.
High beam indicator lamp lights up blue – High beam is switched on.
Temperature warning lamp lights up red – Coolant has reached a critical
value.
Fuel level warning lamp lights up orange – Fuel level has reached the reserve
mark. Display switches to
TRIP F.
FI warning lamp (MIL) lights/flashes orange – The OBD has detected an
emission- or safety-critical error.
