Refitting the headlight mask with the headlight, Maintenance work on chassis and engine – KTM 690 ENDURO EU User Manual
Page 116
MAINTENANCE WORK ON CHASSIS AND ENGINE
114
9.57
Refitting the headlight mask with the headlight
100294-11
– Connect the connectors of headlight
and flasher lights
.
– Check lighting function.
100295-10
– Remove the cloth from the fender, attach the headlight mask to points
on the fender
and swing it up to the steering head.
