TECHNICAL DATA - ENGINE TIGHTENING TORQUES
154
16 TECHNICAL DATA - ENGINE TIGHTENING TORQUES
Plug, oil bore self-tapping 9 Nm (6.6 lbf ft) Loctite ® 243™
Screw, membrane fixation M3 2.5 Nm (1.84 lbf ft) Loctite ® 243™
Oil jet, conrod lubrication M4 2 Nm (1.5 lbf ft) Loctite ® 243™
Hose clamp, intake flange M4 1.5 Nm (1.11 lbf ft) –
Screw, cover plate for oil return line M5 6 Nm (4.4 lbf ft) –
Screw, breather cover on valve cover M5 3 Nm (2.2 lbf ft) Loctite ® 243™
Screw, gear sensor M5 5 Nm (3.7 lbf ft) Loctite ® 243™
Screw, clutch spring M5 6 Nm (4.4 lbf ft) –
Locking screw for bearing M5 6 Nm (4.4 lbf ft) Loctite ® 648™
Screw, oil filter cover M5 6 Nm (4.4 lbf ft) –
Screw, oil pump cover M5 6 Nm (4.4 lbf ft) Loctite ® 243™
Oil jet, piston cooling M6x0.75 4 Nm (3 lbf ft) Loctite ® 243™
Screw, locking lever M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw, Autodecompression M6 3… 4 Nm (2.2… 3 lbf ft) Loctite ® 243™
Screw, axial lock of camshaft M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw generator cover M6 10 Nm (7.4 lbf ft) –
Screw in generator cover (chain shaft
through-hole) M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw, ignition pulse generator M6 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw, rocker arm shaft M6 12 Nm (8.9 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch slave cylinder M6x20 10 Nm (7.4 lbf ft) Loctite ® 243™
Screw, clutch slave cylinder M6x35 10 Nm (7.4 lbf ft) –
