MAINTENANCE WORK ON CHASSIS AND ENGINE
130
100281-10
– Remove screws  .
– Remove the cover
 with membrane  .
– Check the fluid level.
Fluid level under top level of container. 4 mm (0.16 in)
» If the fluid level does not meet specifications:
– Correct the fluid level of the hydraulic clutch.
Hydraulic fluid (15) ( P. 167)
– Check parts for damage and wear. Replace damaged or worn parts.
– Position the cover with the membrane. Mount and tighten screws.
9.72
Checking play in gas Bowden cable
400192-10
– Move the handlebar to the straight-ahead position. Move the throttle grip backwards
and forwards to ascertain the play in the gas Bowden cable.
Play in gas Bowden cable 3… 5 mm (0.12… 0.2 in)
» If the gas Bowden cable play does not meet specifications:
– Adjust the play in the gas Bowden cable. x ( P. 131)
