Figure 24 – Speed Queen Drying Tumblers none User Manual
Page 57
Adjustments
55
70256801
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 24
TMB2208N
NOTE: Tumbler is shown with all guards removed for installation purposes only. Never operate tumbler with the
guards removed.
1
Motor Pulley
7
1/2 in. (13 mm) Deflection
2
Cylinder Motor
8
Guide Rail
3
Locknut
9
Idler Housing
4
Adjusting Bolt
10
Idler Housing Attaching Bolt and Nut
5
Cylinder Sprocket
11
Sheave
6
Cylinder Drive Chain
12
Poly V-Belt
1
2
3
4
5
6
7
8
9
10
8
12
11
7
BELT/CHAIN REVERSING
