Speed Queen Clothes Dryer User Manual
Vended, Vended stack tumble dryer specifications, A passion to lead

Vended
Coin/Card-Operated Stack Tumble Dryers
www.speedqueen.com
AC10-0628
A Passion to Lead
30 lb (13.6 kg) Tumble Dryer
45 lb (20.4 kg) Tumble Dryer
Vended Stack Tumble Dryer Specifications
*Not available in EU
Tumble dryer models are made to suit a variety of electrical service characteristics. See your Speed Queen distributor for specifications. For further
details on installation, refer to Installation, Operation and Maintenance instructions supplied with the tumble dryer. Amperage ratings available in Installa-
tion Manual.
For the most accurate information, the installation guide should be used for all design and construction purposes. Due to continuous product
improvements, design and specifications subject to change without notice. The quality management system of Alliance Laundry Systems’ Ripon
facility has been registered to ISO 9001:2000.
©Copyright 2010 Alliance Laundry Systems LLC
STT30
STT45
Control Option
Gold, MDC
Gold, MDC
Dry Capacity - lb (kg)
2 @ 30 (13.6)
2 @ 45 (20.4)
Filling Ratio - lb (kg)
20:1 = 33 (15.1)
20:1 = 46 (21.1)
Width - in (mm)
31 1/2" (800)
34 1/2" (876)
Depth - in (mm)
42 7/8" (1086)
48 5/8" (1235)
Height - in (mm)
76 1/4" (1937)
81 1/16" (2059)
Cylinder Diameter - in (mm)
30" (762)
33" (838)
Cylinder Depth - in (mm)
26" (660)
30" (762)
Cylinder Volume - cu. ft. (liters)
10.6 (301)
14.8 (421)
Door Opening Size - in (mm)
22 5/8" (576)
26 7/8" (683)
Airflow - cfm (liter/sec)
60 Hz: 400 (189)
60 Hz: 600 (283)
50 Hz: 340 (160)
50 Hz: 500 (236)
Air Outlet Diameter - in (mm)
1 x 8" (203)
1 x 10" (254)
Energy Data
Gas Models:
Gas Models:
146,000 Btu/hr (42.8 kW) total
190,000 Btu/hr (55.6 kW) total - 60Hz
Steam Models:
174,000 Btu/hr (51.0 kW) total - 50 Hz
At 100 psi (6.9 bar): 3.2 BHP,
111,000 Btu/hr (32.5 kW)
Electric Models:
21 kW
Electrical Specifications
Gas and Steam Models:
Gas Models Only:
120/208–240/60/1; 2W/3W+G
200/60/1; 2W+G
100/200-220/60/1; 2W+G
208-240/60/1; 3W+G
100/200/50/1; 2W+G
200-208/240/60/3; 3W+G
230–240/50/1; 2W+G
200/50/1; 2W+G
200-208/240/60/3; 3W+G
230-240/50/1; 2W+G
380/60/3; 3W+G
200/50/3; 3W+G
230–240/50/3; 3W+G
380/400–415/50/3; 3W+G
460-480/60/3; 3W+G
Electric Models:
200–208/60/3; 3W+G
200/50/3; 3W+G
230-240/50/3; 3W+G *
240/60/3; 3W+G
380/60/3; 3W+G
380/50/3; 3W+G
400–415/50/3; 3W+G
460–480/60/3; 3W+G
Motor Size - HP (W)
Fan
1/4 (187)
1/2 (375)
Cylinder
1/4 (187)
1/2 (375)
Plumbing Connections
Gas Models: 1/2" - NPT
Gas Models: 1/2" - NPT
One manifold gas connection.
One manifold gas connection.
Steam Models: 3/4" - NPT
Width
32 1/2" (825)
35 1/2" (902)
Depth
47" (1194)
54" (1372)
Height
81" (2057)
85" (2159)
Net Weight - lb (kg)
544 (247)
673 (305)
Shipping Weight - lb (kg)
582 (264)
718 (326)
Agency Approvals
Gas Models: CSA Star, CSA Flame,
Gas Models: CSA Star, CSA Flame,
cCSAus, CE, Australia Gas
cCSAus, CE, Australia Gas
Electrical & Steam Models: cCSAus, CE
Shipping Dimensions
Approx. - in (mm)
