Specifications and Dimensions
Specifications 50 Pound 75 Pound 634
Net Weight: Pounds (kg)
545 (247) 615 (279) 710 (322)
Cylinder Size: Inches (mm)
37 x 30 (940 x 762) 37 x 36 (940 x 914) 37 x 36 (940 x 914)
Cylinder Capacity (Dry Weight):
Pounds (kg)
50 (22.7) 75 (34) 75 (34)
Air Outlet Diameter: Inches (mm)
8 (203) 8 (203) 10 (254)
Maximum Static Back Pressure:
W.C.I. (mbar)
0.5 (1.3) 0.5 (1.3) 0.5 (1.3)
Maximum Airflow:
C.F.M. (l/sec.)
All Models
Except EG 750 (354) 750 (354)
CG: 920 (434)
1100 (518)
EG Models 390 (184) 500 (236) Not Applicable
Gas Models
Gas Connection
1/2 in. NPT 1/2 in. NPT 3/4 in. NPT
Gas Consumption:
Btu/hr (Mj/hr)
CG Models 120,000 (126.6) 165,000 (174.1) 215,000 (227)
EG Models 95,000 (100.2) 140,000 (147.7)
Electric Models
Heating Elements: Watts
21,000 (240 V/50 Hertz)
30,000 (other voltages)
30,000
Not Applicable
Steam Models
Steam Connection
3/4 in. NPT 3/4 in. NPT Not Applicable
Steam Consumption:
Boiler Horsepower
(Btu)
6 coil
(SH Models)
4.6
(154,000)
4.6
(154,000)
4 coil
(SL Models)
3.0
(100,400)
4.0
(133,900)
Not Applicable
Motor Horsepower
50 Pound 75 Pound 634
Nonreversing
1/2 3/4 Not Applicable
Reversing
Fan 1/3 1/3 1
Cylinder 1/3 1/3 1/3
