Chapter 2
Cabling an 885ix system to
a HAWM-UX/UF
Mounting your HAWM-UX/UF mobility switch ................................................ 6
Placing cables for HAWM-UX/UF-mounted components ............................... 7
Placing cables for other components............................................................ 13
Introduction
SMART Board 885ix interactive whiteboard systems always include a SMART UX60
ultra-short-throw projector and an extended control panel (ECP) located on the
interactive whiteboard.
IMPORTANT
Before following these instructions, install your HAWM-UX/UF and interactive
whiteboard system according to the SMART HAWM-UX/UF installation guide
(
). The instructions below are a supplement to, and not
a substitute for, the installation guide.
