Cabling a 685ix or D685ix
system to a HAWM-UX/UF
Mounting your HAWM-UX/UF mobility switch .............................................. 37
Placing cables for HAWM-UX/UF-mounted components ............................. 39
Placing cables for other components............................................................ 46
Introduction
SMART Board 685ix and D685ix interactive whiteboard systems always include a
SMART UX60 ultra-short-throw projector and an extended control panel (ECP)
located on the interactive whiteboard.
IMPORTANT
Before following these instructions, install your HAWM-UX/UF and interactive
whiteboard system according to the SMART HAWM-UX/UF installation guide
(
). The instructions below are a supplement to, and not
a substitute for, the installation guide.
