Cabling an 880i4 or 885i4
system to a HAWM-UX/UF
Mounting your HAWM-UX/UF mobility switch .............................................. 24
Placing cables for HAWM-UX/UF-mounted components ............................. 26
Placing cables for other components............................................................ 35
Introduction
The SMART Board 880i4 and 885i4 interactive whiteboard systems include a SMART
UF65 high-offset projector or SMART UF65w projector high-offset widescreen
projector, both with a 3D projection option and an extended control panel (ECP) that’s
located on the interactive whiteboard.
IMPORTANT
Before following these instructions, install your HAWM-UX/UF and interactive
whiteboard system according to the SMART HAWM-UX/UF Installation Guide
(
). The instructions below are a supplement to, and not
a substitute for, the installation guide.
