19 | CHAPTER 2 – CABLING AN 885ix SYSTEM TO A HAWM-UX/UF
To connect your projector
power cable on the
HAWM-UX/UF
1. Connect the power cable to the projector’s power socket.
2. Place the power cable through the foam-padded section of the cable clip, located
under the projector, increase the length of cable between the projector and the
clip by 1" (2.5 cm) and then close the clip.
3. Place the power cable around the back of the HAWM-UX/UF toward the left side
of the interactive whiteboard if the power outlet is located on the left or toward the
right side of the interactive whiteboard if the power outlet is located on the right.
4. Connect the other end of the power cable to a power outlet no more than 72"
(183 cm) away from the projector. This distance includes the amount of slack you
need for the projector’s range of movement. If necessary, use a power cable
extension of an appropriate length that includes a minimum of 28" (71.1 cm)
excess straight length or a 14" (35.6 cm) loose loop of cable.
5. Slowly test the movement of the unit, using the HAWM-UX/UF’s mobility switch.
Make sure that the cable isn’t taut at any range of the HAWM-UX/UF’s movement.
TIP
Find a support location for the power cable that doesn’t interfere with the
movement of the HAWM-UX/UF and attach a cable management clip (not
included) to the cable. Make sure that you have enough slack for the
HAWM-UX/UF to move freely, and then bundle the excess. This is strongly
recommended.
To connect your
projector’s network or
peripheral device cables
on the HAWM-UX/UF
1. If you don’t want to connect a network cable, proceed to step 3. Otherwise, make
sure you have a network cable with RJ45 plugs (not included) long enough to
connect your projector to a LAN port.
2. Connect the RJ45 plug on the network cable to the RJ45 port on the projector.
Make sure that the network cable is in the middle left position in the cable slot.
3. Connect your peripheral device cables to the appropriate locations on the
projector’s connection panel.
4. Place all cables through the foam-padded section of the cable clip, located under
the projector. Increase the length of cable between the projector and the clip by 1"
(2.5 cm) and then close the clip.
