5
Computer Input
Select Digital zoom +. The On-Screen Menu disappears and
D . zoom + appears. Press the SELECT button to expand the
image size. Use the Point ▲▼◄► buttons to pan the image.
The Panning function can work only when the image is larger
than the screen size.
A projected image can be also expanded by pressing the
D.ZOOM ▲ or the SELECT button on the remote control.
To exit the Digital zoom +/– mode, press any button except
the D.ZOOM ▲▼ buttons, SELECT and Point buttons.
Digital zoom +
Select Digital zoom –. The On-Screen Menu disappears and
D . zoom – appears. Press the SELECT button to compress
image size.
The projected image can be also compressed by pressing the
D.ZOOM ▼ or the SELECT button on the remote control.
Digital zoom –
To return to the previous screen size, select a screen size
from the Screen Size Adjustment Menu or select an input
source from the Input Source Selection Menu (see page
27) again, or adjust the screen size with the D.ZOOM ▲▼
buttons.
For zooming in and out the images
✔ Note:
• The minimum compression ratio is limited
depending on the input signal, when the
Keystone function is working or when the
custom is selected for the screen size.
• True, Full, and Digital zoom +/– cannot
be selected when 480i, 575i, 480p or
575p is selected in the PC System Menu
(p.28).
• Digital zoom +/- cannot be selected
when Full or True is selected.
• When Custom is selected, the Digital
zoom - function is disabled.
Remote Control
D .ZOOM + button
POINT buttons
SELECT button
D .ZOOM - button
Adjust the screen scale and position manually with this
function.
Press the Point ► button at Custom adj. and the Custom
adjustment menu is displayed on the screen, you can use
the Point ▲▼ buttons to choose the item you want to adjust.
Scale H/V .......... Adjust the Horizontal/Vertical screen
scale.
H&V ................... When set to On, the aspect ratio is
fixed. The Scale V appears dimmed and
becomes unavailable. Adjust Scale H,
then the screen scale is automatically
modified based on the aspect ratio.
Position H/V ..... Adjust the Horizontal/Vertical screen
position.
Common ........... Save the adjusted scale or position to all
the inputs. Press the SELECT button at
Common to display a confirmation box.
To save the scale or position, press the
SELECT button at yes. When Custom
is selected, the saved scale or position is
used.
Reset ................. Reset the all adjusted values. Press
the SELECT button at Reset to display
a confirmation box. To reset, press the
SELECT button at yes.
Custom adj .
✔ Note:
• When no signal is detected, Normal is set
automatically .
• The adjustable range for Scale H/V and
Position H/V is limited depending on the
input signal.
►
adj.
