29
Computer Input
Auto PC Adjustment function is provided to automatically adjust Fine sync, Total dots, Horizontal and Vertical
positions to conform to your computer.
PC adjust Menu
Auto PC Adjustment
To store adjustment parameters
The adjusted parameters from the Auto PC Adjustment can
be stored in the projector. Once the parameters are stored,
the setting can be done just by selecting a Mode (1–10) in
the PC System Menu (see page 28). See also “Store” on
page 31.
✔ Note:
• Fine sync, Total dots, Horizontal and Vertical
position of some computers cannot be fully adjusted
with the Auto PC Adjustment function. When the image
is not provided properly with this operation, manual
adjustments are required (pp.30-31).
• The Auto PC Adjustment cannot be operated when 480i,
575i, 480p, 575p, 720p,105i or 1080i is selected in the
PC System Menu (p.28).
Press the MENU button to display the On-Screen
Menu. Use the Point ▲▼ buttons to select PC adjust
and then press the Point ► or the SELECT button.
1
2 Use the Point ▲▼ buttons to select Auto PC adj . and
then press the SELECT button.
Auto PC adj .
Menu Operation
Auto PC adj.
Fine sync
Total dots 1365
Horizontal 0
Vertical 0
Current mode
Clamp 0
Display area H 1024
Display area V 768
Reset
Mode free
Store
0
►
Use Point ▲▼ buttons to select Auto PC
adj . and press the SELECT button.
Please wait . . . appears while the Auto PC
adjustment is in process.
Auto PC adj.
Fine sync
Total dots 1365
Horizontal 0
Vertical 0
Current mode
Clamp 0
Display area H 1024
Display area V 768
Reset
Mode free
Store
0
►
