4
Computer Input
Store
This projector has the picture screen resize function, which
enables you to customize the image size.
Screen Menu
Screen Size Adjustment
Provide the image to fit the screen size.
Normal
True
Provide the image in its original size. When the original
image size is larger or smaller than the screen size
(1024 x 768), the projector enters to the panning mode
automatically. Use the Point ▲▼◄► buttons to pan the
image. When adjusted, the arrows will turn red. When
reached to the correction limits, the arrows will disappear.
Full
Provide the full screen image.
✔ Note:
• The Screen Menu, only Normal and Custom can be operated, wide will be disabled and displayed in gray
when 720p, 105i, or 1080i is selected in the PC System Menu (p.28).
• This projector cannot display any resolution higher than 1920 x 1200. If your computer’s screen resolution is
higher than it, reset the resolution to the lower before connecting to the projector.
• The image data in other than 1024 x 768 is modified to fit the screen size in initial mode.
• True, Full, and Digital zoom +/– are disabled and cannot be displayed when 480i, 575i, 480p or 575p is
selected in the PC System Menu (p.28).
1
2
To store the adjusted data, select Store and press the Point
►or the SELECT button. Use the Point ▲▼ buttons to
select one from Image 1 to 4 and press the SELECT button.
A confirmation box appears and then select yes. Stored
data can be called up by selecting an Image (1–4) in the
Image Mode Selection on page 32.
Press the MENU button to display the On-Screen
Menu. Use the Point ▲▼ buttons to select Screen and
then press the Point ► or the SELECT button.
Use the Point ▲▼ buttons select the desired item and
then press the SELECT button .
A confirmation box appears and
then select yes.
Image 1
Image 2
Image 3
Image 4
Where to store?
►
Normal
True
Wide
Full
Custom
Custom adj.
Digital zoom +
Digital zoom -
►
Normal
True
Full
Wide
Custom
Custom adj.
Digital zoom +
Digital zoom -
►
Custom
Provide the last stored aspect screen image.
wide
Provide the image to fit the wide video aspect ratio (16:9) by
expanding the image width uniformly. This function can be
used for providing a squeezed video signal at 16:9.
