AR-5127 SIMULATION 8 - 38

When there are two or more send/receive operations of image data in
one communication, only the time of the last send/receive data near
the end is measured.
Note: Executable only when the FAX is installed.

Operation/procedure
The following test sound is delivered to the line and the speaker to
adjust the sound kind and volume.
The send level to the line is the set value of soft SW.
The set values of the selected sound kind and volume are written to
each soft SW.
1. Sound kinds pattern

NS=No Sound S=Small M=Medium L=Large
2. Sound volume pattern

S=Small M=Medium L=Large
Note: Executable only when the FAX is installed.

Operation/procedure
Read/write the time (year, month, day, min., sec.) on RTC of FAX
PWB.
Note: Executable only when the FAX is installed.

Operation/procedure
The call signal from CI pin is detected to deliver the call sound to the
line and the speaker. The volume of call sound follows the soft SW.
Signal detection and delivery of pseudo-call sound at detection are
executed until the interruption command is provided by pressing the
[BACK] key.
Note: Executable only when the FAX is installed.

Operation/procedure
SRAM data in FAST area is initialized.
Note: Executable only when the FAX is installed.

Operation/procedure
The detection test of signals is performed and the test result is dis-
played.
1. Detected signal

CI displays the detected ring pattern simultaneously.

How to check the time

Enter the simulation for communication time
check and check the time.

Measuring unit

msec

66-37

Purpose

Adjustment/Setting/Check

Function
(Purpose)

Speaker sound volume adjustment

Related soft SW

SW 86-1, 2 (call sound)
SW 85-1, 2 (line monitor sound)
SW 84-1, 2 (on hook)
SW 88-1, 2 (read end sound)
SW 89-1, 2 (communication end sound)
SW 87-1, 2 (DTMF send sound)
SW75-1, 2 (send end sound length)
SW75-3, 4 (receive end sound length)

Sound kinds
(Test sound)

Sound volume set value

Sound

volume
Pattern

0

1

2

3

1

Call sound

NS

S

M

L

01 to 35

2

Line monitor sound
(Test sound:
Communication
signal sound)

NS

S

M

L

01 to 35

3

On hook
(Test sound:
Communication
signal sound)

Setting

Disable

S

M

L

01 to 35

4

Read complete
sound

NS

S

M

L

01 to 35

5

Communication
end sound

NS

S

M

L

01 to 35

6

DTMF signal send
sound

NS

S

M

L

01 to 35

Sound

volume

VR set value

Sound

volume

VR set value

1

2

3

4

5

6

7

1

2

3

4

5

6

7

01

S M L

20

S

M L

02

S M

L

21

S

M

L

03

S M

L

22

S

M

L

04

S M

L

23

S

M L

05

S M

L

24

S

M

L

06

S

M L

25

S

M L

07

S

M

L

26

S M L

08

S

M

L

27

S M

L

09

S

M

L

28

S M

L

10

S

M L

29

S

M L

11

S

M

L

30

S

M

L

12

S

M

L

31

S

M L

13

S

M L

32

S M L

14

S

M

L

33

S M

L

15

S

M L

34

S

M L

16

S M L

35

S M L

17

S M

L

18

S M

L

19

S M

L

66-38

Purpose

Adjustment/Setting/Check

Function
(Purpose)

Time setting/check

66-41

Purpose

Adjustment/Setting/Check

Function
(Purpose)

CI signal check

Related soft SW

SW12-6 to 7, SW55-1 to 7

66-50

Purpose

Adjustment/Setting/Check

Function
(Purpose)

FAST SRAM clear

66-51

Purpose

Adjustment/Setting/Check

Function
(Purpose)

Signal detection check

Related soft SW SW13-3, 4 (call sound volume)

SW32-1 to 4 (Distinctive Ring)
SW12-6, 7 (CI detection pattern)
(00:4 Sine wave 10:3 Sine wave 01:2 Sine wave)
SW26-3, 4 (speaker volume)
SW35-3, 4 (CI extinction maximum OFF time)
SW51-7, 8 (BT detection cycle)
SW52-1, 2 (BT/DT detection level)
SW55-1 to 7 (detection possible time of CI
signal)
SW56-5, 6 (DT, BT filter efficiency)
SW56-7 (DP, BT detection level)

Detected in off-hook.

CI, CNG, FNET, DTMF

Detected in off-hook.

BusyTone, CNG
DialTone, CED
SDT, flag, DTMF

Sound

volume

VR set value

Sound

volume

VR set value

1

2

3

4

5

6

7

1

2

3

4

5

6

7
