AR-5127 SIMULATION 8 - 26
Operation/procedure
Enter the adjustment value with the 10-key and press the [OK] key, and
the entered value is registered.
Operation/procedure
To support an individual necessity in paper and the environment, it is
variable in the range of 5 to 30uA in the increment of 1uA in each
mode.
When changing +V2, check with +V1 unchanged. If there is any trouble
in the half tone image of graphics, keep the relationship between +V1
and +V2 at the default and change it.
When the image quality is deteriorated because the user selects the
OHP mode and use other than the recommended OHP, decrease the
transfer current to adjust deterioration of black background picture
quality. If some of characters are not printed, increase the transfer cur-
rent.
Operation/procedure
Correction is performed when the temperature sensor installed to the
MCU indicates 15°C or below.
The content of correction is to raise the DVB-Bias and Grid by –50V.
The simulation allows to vary the correction threshold value in the
range of 0 to 20°C.
If, however, the set temperature is increased, correction at a high volt-
age is performed in normal temperatures.
Operation/procedure
Enter the set value with the 10-key, and the set value will be registered.
Operation/procedure
Select the mode with the arrow keys, enter the adjustment value with
the 10-key, and press the [OK] key.
When the [START] key is pressed, a print is made and the display
returns to the mode selection menu.
(Auto adjustment)
Setup of various copy conditions: Similar to the normal copy mode.
44
44-1
Purpose Setting
Function
(Purpose) Used to make various setups in each mode of process
control.
Section Image process (Photoconductor/Developing/Transfer/
Cleaning)
Item Operation
Display items Content
Setting
range
Default
ENVIRONMENT ADJ.
Environmental correction
Valid/Invalid
(0: Environmental
correction invalid
1: Environmental
correction valid)
0-1 1
44-34
Purpose Adjustment
Function
(Purpose) Used to adjust the transfer current value.
(Initial screen) (Input/Executing screen)
Display items Content
Setting
range
Default
1:+V1 (600) 600dpi +V1 5-30 16
2:+V2 F (600) 600dpi +V2 front surface 5-30 20
3:+V2 R (600) 600dpi +V2 back surface 5-30 16
4:+V2 S-F(600) 600dpi +V2 small size front 5-30 22
5:+V2 S-R(600)
600dpi +V2 small size back 5-30 16
6:+V2 OHP(600)
600dpi +V2OHP 5-30 16
7:+V1 (1200)
1200dpi +V1 5-30 Disabled
8:+V2 F (1200) 1200dpi +V2 front surface 5-30 Disabled
9:+V2 R (1200) 1200dpi +V2 back surface 5-30 Disabled
10:+V2 S-F(1200) 1200dpi +V2 small size front 5-30 Disabled
11:+V2 S-R(1200) 1200dpi +V2 small size
back 5-30 Disabled
12:+V2 OHP(1200) 1200dpi +V2OHP 5-30 Disabled
Sim44-1 PROCON MODE
ENVIRONMENT ADJ. 1
[ 0- 1] 1
Sim44-34 TC ADJ.
1:+V1 (600) 16
2:+V2 F (600) 20
3:+V2 R (600) 16
1/4
Sim44-34 TC ADJ.
4:+V2 S-F(600) 22
[ 5- 30] 22
44-35
Purpose Setting
Function
(Purpose) Correction temperature setup when correcting the
ambient temperature.
Setting range 0-20
Default 15°C
44-40
Purpose Setting
Function
(Purpose) Used to set the rotating time before toner supply.
Setting range 1-99
Default 8
46
46-2
Purpose Adjustment
Function
(Purpose) Used to adjust the copy exposure level.
Item Picture quality Density
(Initial screen) (Input screen) (Executing screen)
Display items Content
Setting
range
Default
1:AE AE 1-99 50
2:TEXT Character Level 3.0
3:TEXT/PHOTO Character/Photo Level 3.0
4:PHOTO Photo Level 3.0
5:SUPER PHOTO * Super photo Level 3.0 Disabled
6:AE(TS) AE (TS)
50 7:TEXT(TS)
Character (TS) Level 3.0
8:TEXT/PHOTO(TS) Character/Photo (TS) Level 3.0
Sim44-35 ENV.ADJ.
DVB/GRID ENV TMP 15
[ 0- 20] 15
Sim44-40 TONER
ROTATE TIME 50
[ 1- 99] 8
Sim46-2 EXP. LEVEL
1:AE 50
2:TEXT 50
3:TEXT/PHOTO 50
1/3 50
