AR-5127 SIMULATION 8 - 19
• "TONER UNIT NONE"
• "EU ERROR"
• "EL ERROR"
Operation/procedure
Set the job separator.
Operation/procedure
Used to set the automatic size detection.
8.5" x 13" detection valid/invalid setup
Detection size when 8.5" x 13" document/paper is used.
Cancel procedure: It returns to the state before execution of auto
developer adjustment. It is canceled by the
operations of Cover open
→ Developing unit
installation → Cover close. Therefore, developer
adjustment is started by pressing [OK] key.
Error content: Occurs when the CRUM is not installed in a DM
model.
Cancel procedure: It returns to the state before execution of auto
developer adjustment. It is canceled by the
operations of Cover open
→ CRUM installation →
Cover close. Therefore, developer adjustment is
started by pressing [OK] key.
Error content: Occurs when the toner concentration reference
value calculated in developer adjustment finally
is 179 or greater.
Cancel procedure: Reset with [CA] key and execute SIM 25-2 again.
Error content: Occurs when the toner concentration reference
value calculated in developer adjustment finally
is 77 or smaller.
Cancel procedure: Reset with [CA] key and execute SIM 25-2 again.
26
26-1
Purpose Setting
Function
(Purpose) Used to set options. (This simulation is used to make
option setting when an option is installed.)
Item Specifications Option
Set value Connection option
0 None (default)
1 Job separator provided.
26-2
Purpose Setting
Function
(Purpose) Used to detect the paper size.
Section Paper feed
Item Specifications
1:B4/LG,FC Setting to detect B4/Legal as FC
0: B4 legal is detected as B4 legal.
1: B4 legal is detected as FC.
2:A4<->LT This setup detects Letter as A4 in the inch series and
A4 as Letter in the AB series.
0: Detection disable
1: Detection valid
(Initial screen) (Input screen)
Set value Setup Remarks
0 Detection invalid Default
1 Detection valid
Sim26-1 OPTION SET.
JOB SEPARATOR 0
(0:NONE
1:JOB SEPARATOR)
[ 0- 1] 0
Sim26-2 SIZE SET
1:B4/LG,FC 0
2:A4<->LT 0
1
Sim26-2 SIZE SET
1:B4/LG,FC 0
(0:OFF 1:ON)
[ 0- 1] 1
Employed unit Destination Document size
Set value
0
(Invalid)
1
(Valid)
Document Document
table/SPF AB series (Japan) FC (8.5” x 13”) B4 B4
LG (8.5” x 14”) B4 B4
B4 B4 B4
AB series FC (8.5” x 13”) B4 FC (8.5” x 13”)
LG (8.5” x 14”) B4 FC (8.5” x 13”)
B4 B4 FC (8.5” x 13”)
Inch series FC (8.5” x 13”) LG (8.5” x 14”) FC (8.5” x 13”)
LG (8.5” x 14”) LG (8.5” x 14”) FC (8.5” x 13”)
B4 WLT (11” x 17”) WLT (11” x 17”)
Paper Machine paper
feed cassette All destinations
– Set with key operations.
Manual paper
feed tray Japan (AB series) FC (8.5” x 13”) LG (8.5” x 14”) LG (8.5” x 14”)
LG (8.5” x 14”) LG (8.5” x 14”) LG (8.5” x 14”)
B4 B4 B4
AB series FC (8.5” x 13”) LG (8.5” x 14”) FC (8.5” x 13”)
LG (8.5” x 14”) LG (8.5” x 14”) FC (8.5” x 13”)
B4 B4 B4
Inch series FC (8.5” x 13”) LG (8.5” x 14”) FC (8.5” x 13”)
LG (8.5” x 14”) LG (8.5” x 14”) FC (8.5” x 13”)
B4 B4 B4
