AR-5127 SIMULATION 8 - 17
Operation/procedure
Each counter is cleared individually. (The history of each counter is
deleted when clearing)
Operation/procedure
Clear the counters individually.
Operation/procedure
Clear the counters individually.
Operation/procedure
Press the [OK] key.
Operation/procedure
Press the [OK] key.
Operation/procedure
Press the [OK] key.
Operation/procedure
Press the [OK] key.
24
24-1
Purpose
Data clear
Function
(Purpose)
Used to clear the misfeed counter, the misfeed history,
the trouble counter, and the trouble history. (The
counters are cleared after completion of maintenance.)
Item
Counter
(Initial screen)
(Check screen)
1:JAM
JAM counter/JAM history
2:SPF JAM
SPF JAM counter/SPF JAM history
3:TROUBLE
Trouble counter/Trouble history
24-2
Purpose
Data clear
Function
(Purpose)
Used to clear the number of use (the number of prints)
of each paper feed section.
Section
Paper feed
Item
Counter
(Initial screen)
(Check screen)
1:BYPASS
Manual feed counter
4:TRAY3
Tray 3 counter
2:TRAY1
Tray 1 counter
5:TRAY4
Tray 4 counter
3:TRAY2
Tray 2 counter
24-3
Purpose
Data clear
Function
(Purpose)
Used to clear the number data of use of the staple, the
SPF and scanning.
Item
Counter
(Initial screen)
(Check screen)
1:SPF
SPF counter
2:SCAN
Scan counter
3:STAPLE
Stapler counter
Sim24-1 COUNTER CLR
1:JAM
2:SPF JAM
3:TROUBLE
2
Sim24-1 COUNTER CLR
1:JAM
2:
SPF JAM
3:TROUBLE
ARE YOU SURE?
2
Sim24-2 COUNTER CLR
1:BYPASS 4:TRAY3
2:TRAY1 5:TRAY4
3:TRAY2
2
Sim24-2 COUNTER CLR
1:BYPASS 4:TRAY3
2:
TRAY1
5:TRAY4
3:TRAY2
ARE YOU SURE?
2
Sim24-3 COUNTER CLR
1:SPF
2:SCAN
3:STAPLE
2
Sim24-3 COUNTER CLR
1:SPF
2:
SCAN
3:STAPLE
ARE YOU SURE?
2
24-4
Purpose
Data clear
Function
(Purpose)
Used to reset the maintenance counter.
Item
Counter
(Initial screen)
(Check screen)
24-5
Purpose
Data clear
Function
(Purpose)
Used to reset the developer counter. (The developer
counter of the DV unit which is installed is reset.)
Section
Image process (Photoconductor/Developing/Transfer/
Cleaning)
Developer/Toner hopper
Item
Counter
Developer
(Initial screen)
(Check screen)
24-6
Purpose
Data clear
Function
(Purpose)
Used to reset the copy counter.
Item
Counter
Copier
(Initial screen)
(Check screen)
24-7
Purpose
Data clear
Function
(Purpose)
Used to clear the OPC drum (membrane decrease)
correction counter. (This simulation is executed when
the OPC drum is replaced.
Section
Image process (Photoconductor/Developing/Transfer/
Cleaning)
Photo conductor
Item
Counter
(Initial screen)
(Check screen)
Sim24-4 COUNTER CLR
MAINTENANCE COUNTER
CLEAR
PRESS OK KEY
Sim24-4 COUNTER CLR
MAINTENANCE COUNTER
CLEAR
ARE YOU SURE?
Sim24-5 COUNTER CLR
DEVELOPER COUNTER
CLEAR
PRESS OK KEY
Sim24-5 COUNTER CLR
DEVELOPER COUNTER
CLEAR
ARE YOU SURE?
Sim24-6 COUNTER CLR
COPIES COUNTER
CLEAR
PRESS OK KEY
Sim24-6 COUNTER CLR
COPIES COUNTER
CLEAR
ARE YOU SURE?
Sim24-7 COUNTER CLR
DRUM COUNTER CLEAR
PRESS OK KEY
Sim24-7 COUNTER CLR
DRUM COUNTER CLEAR
ARE YOU SURE?
