Chapter 13
Removing Switch Components
■ Installing and Removing EX3200 and EX4200 Switch Hardware
Components on page 171
■ Removing a Power Supply from an EX3200 or EX4200 Switch on page 172
■ Removing a Fan Tray from an EX3200 or EX4200 Switch on page 174
■ Removing an Uplink Module from an EX3200 or EX4200 Switch on page 175
■ Removing a Transceiver from an EX Series Switch on page 177
■ Disconnecting a Fiber-Optic Cable from an EX Series Switch on page 179
■ Disconnecting a Virtual Chassis Cable from an EX4200 Switch on page 180
■ Replacing a Member Switch of a Virtual Chassis Configuration (CLI
Procedure) on page 182
Installing and Removing EX3200 and EX4200 Switch Hardware Components
The EX3200 and EX4200 switch chassis is a rigid sheet-metal structure that houses
the hardware components. The field-replaceable units (FRUs) in EX3200 and EX4200
switches are:
■ Power supply
■ Fan tray
■ Uplink module
■ SFP transceiver
■ SFP+ transceiver
■ XFP transceiver
The power supply, fan tray, uplink module, and transceivers are hot-removable and
hot-insertable: You can remove and replace them without powering off the switch
or disrupting switch functions.
To install a power supply in an EX3200 or EX4200 switch, follow instructions in
“Installing a Power Supply in an EX3200 or EX4200 Switch” on page 130. To remove
a power supply from an EX3200 or EX4200 switch, follow instructions in “Removing
a Power Supply from an EX3200 or EX4200 Switch” on page 172.
To install a fan tray in an EX3200 or EX4200 switch, follow instructions in “Installing
a Fan Tray in an EX3200 or EX4200 Switch” on page 132. To remove a fan tray from
Installing and Removing EX3200 and EX4200 Switch Hardware Components ■ 171
