Juniper Networks EX4200 User Manual
Page 153

Figure 45: Mounting an EX3200 or EX4200 Switch on a Wall
Hang attached brackets
on wall-mounted screws.
g020201
Front
panel
Rear panel
5.
Tighten the mounting screws.
6.
If it is an EX4200-24F switch, we recommend you insert dust covers in unused
SFP ports.
Related Topics
■
Connecting AC Power to an EX3200 or EX4200 Switch on page 146
■
Connecting DC Power to an EX3200 or EX4200 Switch on page 148
■
Connecting and Configuring an EX Series Switch (CLI Procedure) on page 161
■
Connecting and Configuring an EX Series Switch (J-Web Procedure) on page 163
■
Wall-Mounting Warning for EX3200 and EX4200 Switches on page 225
Mounting an EX3200 or EX4200 Switch on a Wall
■
127
Chapter 9: Installing the Switch
