50
ADVANCED OPERATIONS (cont.)
L-1 OUTPUT/INPUT Setting
The AV1 (L-1) IN/OUT connector accepts and delivers either a composite signal (regular video signal) or a Y/C signal (a signal in
which the luminance and chrominance signals are separated). Set "L-1 OUTPUT" and "L-1 INPUT" to the appropriate mode
depending on the type of unit connected to the rear panel AV1 (L-1) IN/OUT connector of this recorder.
1
Press MENU to access the Main Menu screen.
2
Press %fi to move the highlight bar (pointer) to "OUTPUT/INPUT SET", then press OK or #
.
3
Press %fi to move the highlight bar (pointer) to "L-1 OUTPUT" or "L-1 INPUT".
4
For "L-1 OUTPUT"
Press OK or
#
to select "VIDEO" or "S-VIDEO".
a–VIDEO : If a connected device's input is compatible only with regular video signals,
set to "VIDEO".
b–S-VIDEO : If a connected device's input is compatible with Y/C signals, set to
"S-VIDEO". This setting will let you take advantage of higher-quality
S-VHS pictures. (For connection, be sure to use a 21-pin SCART cable that
is compatible with the Y/C signal.)
For "L-1 INPUT"
Press OK or
#
to select "VIDEO" or "S-VIDEO".
a–VIDEO : If a connected device's output is compatible only with regular video
signals, set to "VIDEO".
b–S-VIDEO : If a connected device's output is compatible with Y/C signals, set to
"S-VIDEO". This setting will let you take advantage of higher-quality
S-VHS pictures. (For connection, be sure to use a 21-pin SCART cable that
is compatible with the Y/C signal.)
5
Press MENU to return to normal screen.
● If "L-1 OUTPUT" is set to "S-VIDEO", it is impossible to set "L-1 INPUT" to "S-VIDEO".
● If "L-2 SELECT" is set to "DECODER", it is impossible to set "L-1 INPUT" to "S-VIDEO".
OUTPUT/INPUT SET
L-1 OUTPUT VIDEO
L-1 INPUT VIDEO
L-2 SELECT A/V
VHS
F-1 INPUT VIDEO
[ 5∞] =
[MENU] : EXIT
L-2 SELECT Setting
Set "L-2 SELECT" to the appropriate mode depending on the type of unit connected to the rear panel AV2 (L-2) IN/DECODER
connector of this recorder.
1
Press MENU to access the Main Menu screen.
2
Press %fi to move the highlight bar (pointer) to "OUTPUT/INPUT SET", then press OK or #
.
3
Press %fi to move the highlight bar (pointer) to "L-2 SELECT".
4
Press OK or
#
to select "A/V", "DECODER" or "SAT".
a–A/V : To use this recorder as the recording deck with the player connected to the
AV2 (L-2) IN/DECODER connector, or to use the satellite receiver con-
nected to the AV2 (L-2) IN/DECODER connector.
b–DECODER : To use a decoder connected to the AV2 (L-2) IN/DECODER connector.
c–SAT
: To view a satellite programme with the TV set while the recorder is turned
off. (
੬
pg. 59)
5
Press MENU to return to normal screen.
● If you have a satellite receiver or a decoder connected to the AV2 (L-2) IN/DECODER connector, be sure to set "L-2 SELECT"
back to appropriate mode after editing.
● If you're not connecting a satellite receiver or a decoder to the AV2 (L-2) IN/DECODER connector, leave "L-2 SELECT" set to
"A/V".
● The default setting is "A/V"; if the recorder's memory backup has expired due to a power cut or because the AC was removed
from the recorder, "A/V" will be automatically selected when the power is restored to the recorder. If you are using a satellite
receiver or a decoder, be sure to set "L-2 SELECT" back to appropriate mode.
● When "L-2 SELECT" is set to "SAT", "SAT" appears on screen or display panel instead of "L-2" or "L2".
● If "L-1 OUTPUT" is set to "S-VIDEO", it is impossible to set "L-2 SELECT" to "DECODER".
OUTPUT/INPUT SET
L-1 OUTPUT VIDEO
L-1 INPUT VIDEO
L-2 SELECT A/V
VHS
F-1 INPUT VIDEO
[ 5∞] =
[MENU] : EXIT
