JVC Model 200 User Manual
Page 27
Chapter 2---System Description
CRTs
OUTPUTS DESCRIPTION
RED_ANODE
GRN_ANODE
BLU_ANODE
Anode supply for the three CRTs. About 25 KV
RED_FOCUS
GRN_FOCUS
BLU_FOCUS
Focus voltage for the three CRTs. About 7 KV
Interlocks and protection:
This section describes the interactions between boards where one
board may cause others to perform protection functions.
Input
A high signal at /HV_ENA shuts off the HVPS.
Model 200 Service Manual
2-13
