vlan-id 200;
}
bd300 {
vlan-id 300;
}
bd500 {
vlan-id 500;
}
bd600 {
vlan-id 600;
}
}
}
Configuring ERP on AS1
CLI Quick
Configuration
To quickly configure AS1 for ERP, copy the following commands and paste them into the
switch terminal window of AS1:
[edit]
set interfaces ge-2/0/5 unit 0 family bridge interface-mode trunk
set interfaces ge-2/0/5 unit 0 family bridge vlan-id-list 100-1000
set interfaces ge-2/1/1 unit 0 family bridge interface-mode trunk
set interfaces ge-2/1/1 unit 0 family bridge vlan-id-list 100-1000
set protocols protection-group ethernet-ring ring-1 east-interface control-channel ge-2/0/5.0
set protocols protection-group ethernet-ring ring-1 east-interface control-channel vlan 100
set protocols protection-group ethernet-ring ring-1 west-interface control-channel ge-2/1/1.0
set protocols protection-group ethernet-ring ring-1 west-interface control-channel vlan 100
set protocols protection-group ethernet-ring ring-1 data-channel vlan [200, 300]
set protocols protection-group ethernet-ring ring-2 east-interface control-channel ge-2/0/5.0
set protocols protection-group ethernet-ring ring-2 east-interface control-channel vlan 101
set protocols protection-group ethernet-ring ring-2 west-interface control-channel ge-2/1/1.0
set protocols protection-group ethernet-ring ring-2 west-interface control-channel vlan 101
set protocols protection-group ethernet-ring ring-2 data-channel vlan [500, 600]
set bridge-domains bd100 vlan-id 100
set bridge-domains bd101 vlan-id 101
set bridge-domains bd200 vlan-id 200
set bridge-domains bd300 vlan-id 300
set bridge-domains bd500 vlan-id 500
set bridge-domains bd600 vlan-id 600
Step-by-Step
Procedure
To configure ERP on AS1:
Configure the trunk interface
ge-2/0/5
to connect CS2 to CS1 and trunk interface
ge-2/1/1
to connect CS2 to CS1, and configure the
family
statement as
bridge
with
a VLAN ID list of 100 through 1000:
1.
[edit interfaces]
user@as1#
set ge-2/0/5 unit 0 family bridge interface-mode trunk
user@as1#
set ge-2/0/5 unit 0 family bridge vlan-id-list 100-1000
user@as1#
set ge-2/1/1 unit 0 family bridge interface-mode trunk
user@as1#
set ge-2/1/1 unit 0 family bridge vlan-id-list 100
2.
Enable ERP, specifying the control channels and data channels for
ring-1
and
ring-2
:
NOTE:
Always configure the
east-interface
statement first, before
configuring the
west-interface
statement.
Copyright © 2013, Juniper Networks, Inc.
170
Junos OS 13.1 MX Series 3D Universal Edge Routers Solutions Guide
