Table 5: Components of the Network Topology (continued)
Settings Property
AS1 has the following protection group properties:
• East interface— ge-2/0/5.0 .
• West interface— ge-2/1/1.0 .
• Data channel for ring-1 — VLAN 200 , VLAN 300 .
• Data channel for ring-2 — VLAN 500 , VLAN 600 .
AS1 has the following bridging properties:
• bd100 is associated with vlan-id 100 .
• bd101 is associated with vlan-id 101 .
• bd200 is associated with vlan-id 200 .
• bd300 is associated with vlan-id 300 .
• bd500 is associated with vlan-id 500 .
• bd600 is associated with vlan-id 600 .
AS1 router
Configuration
To enable ERP with ring instances on CS1, CS2, and AS1, perform these tasks:
• Configuring ERP on CS1 on page 164
• Configuring ERP on CS2 on page 167
• Configuring ERP on AS1 on page 170
Configuring ERP on CS1
CLI Quick
Configuration
To quickly configure CS1 for ERP, copy the following commands and paste them into the
switch terminal window of CS1:
[edit]
set interfaces ge-3/2/4 vlan-tagging
set interfaces ge-3/2/4 unit 0 family bridge interface-mode trunk
set interfaces ge-3/2/4 unit 0 family bridge vlan-id-list 100-1000
set interfaces ge-5/2/3 vlan-tagging
set interfaces ge-5/2/3 unit 0 family bridge interface-mode trunk
set interfaces ge-5/2/3 unit 0 family bridge vlan-id-list 100-1000
set protocols protection-group ethernet-ring ring-1 ring-protection-link-owner
set protocols protection-group ethernet-ring ring-1 east-interface control-channel ge-3/2/4.0
set protocols protection-group ethernet-ring ring-1 east-interface control-channel vlan 100
set protocols protection-group ethernet-ring ring-1 east-interface ring-protection-link-end
set protocols protection-group ethernet-ring ring-1 west-interface control-channel ge-5/2/3.0
set protocols protection-group ethernet-ring ring-1 west-interface control-channel vlan 100
set protocols protection-group ethernet-ring ring-1 data-channel vlan [200, 300]
set protocols protection-group ethernet-ring ring-2 east-interface control-channel ge-3/2/4.0
set protocols protection-group ethernet-ring ring-2 east-interface control-channel vlan 101
set protocols protection-group ethernet-ring ring-2 west-interface control-channel ge-5/2/3.0
set protocols protection-group ethernet-ring ring-2 west-interface control-channel vlan 101
set protocols protection-group ethernet-ring ring-2 data-channel vlan [500, 600]
set routing-instances vs instance-type virtual-switch
set routing-instances vs interface ge-3/2/4.0
set routing-instances vs interface ge-5/2/3.0
set routing-instances vs bridge-domains bd101 vlan-id 101
