Table 5: Components of the Network Topology (continued)
Settings Property
CS1 has the following protection group properties:
• RPL owner— ring-1 .
• East interface— ge-3/2/4.0 .
• West interface— ge-5/2/3.0 .
• Data channel for ring-1 — VLAN 200 , VLAN 300 .
• Data channel for ring-2 — VLAN 500 , VLAN 600 .
• Ring protection link end for ring-1 — ge-3/2/4.0 .
CS1 has the following routing and bridging properties:
• Routing instance— vs .
• Bridge domains:
• bd100 is associated with vlan-id 100 .
• bd101 is associated with vlan-id 101 .
• bd200 is associated with vlan-id 200 .
• bd300 is associated with vlan-id 300 .
• bd500 is associated with vlan-id 500 .
• bd600 is associated with vlan-id 600 .
CS1 router
CS2 has the following protection group properties:
• RPL owner— ring-2 .
• East interface— ge-2/0/4.0 .
• West interface— ge-2/0/8.0 .
• Ring protection link end for ring-2 — ge-2/0/8.0 .
• Data channel for ring-1 — VLAN 200 , VLAN 300 .
• Data channel for ring-2 — VLAN 500 , VLAN 600 .
CS2 has the following bridging properties:
• bd100 is associated with vlan-id 100 .
• bd101 is associated with vlan-id 101 .
• bd200 is associated with vlan-id 200 .
• bd300 is associated with vlan-id 300 .
• bd500 is associated with vlan-id 500 .
• bd600 is associated with vlan-id 600 .
CS2 router
