Because of the translation, the flow of packets and frames between PE1 (the M Series
router) and PE2 (the MX series router) routers is not symmetrical, as is shown in
Figure
11 on page 84 .
Figure 11: ATM Ethernet VLAN Interworking Packet Structure
g017429
MPLS Inner VLAN L3 Ethertype SA DA Ethernet
MPLS Inner VLAN L3 Ethertype SA DA Ethernet
1. PE1 PE2
2. PE2 PE1
“8 bytes” is an ATM cookie added by an M Series ATM pic.
The first 2 bytes of this ATM cookie is inner VLAN.
For PE1 to PE2 traffic, the 8 bytes following the MPLS header is an ATM cookie added by
the M Series ATM PIC. The first two bytes are the inner VLAN tag, which is why the field
extends to the right of the figure.
The traffic between PE2 and CE2 is a normal flow of stacked Ethernet frames.
You can also configure a CCC with remote interface switch or Layer 2 circuit over
Aggregated Ethernet on the MX Series router (PE2). When CCC is configured for
Aggregated Ethernet, the flow of packets is as shown in
Figure 12 on page 84 .
Figure 12: CCC-to-Stacked VLAN Translation
g017430
L3 Ethertype SA DA MPLS Inner VLAN Ethernet
MPLS Inner VLAN L3 Ethertype SA DA Ethernet
1. CCC to stacked-vlan
2. Stacked-vlan to CCC
L3 Ethertype SA DA Ivlan Ovlan
L3 Ethertype SA DA Ivlan Ovlan
