ISDN RJ-45 Connector Pinout
The 1-port and 4-port ISDN PIMs use an RJ-45 cable, which is not supplied with the
PIMs. Table 92 on page 239 describes the RJ-45 connector pinout.
Table 92: ISDN RJ-45 Connector Pinout
Signal Pin
No connect 1
No connect 2
RJ_SX_P 3
RJ_SR_P 4
RJ_SR_N 5
RJ_SX_N 6
No connect 7
No connect 8
Shielded 9
Shielded 2 10
Connector Pinouts for Avaya VoIP Modules
The Avaya VoIP modules supported on the Services Router accept different kinds of
network cables.
■ TGM550 Console Port Pinouts on page 239
■ TGM550 RJ-11 Connector Pinout for Analog Ports on page 240
■ TIM508 Connector Pinout on page 241
■ TIM510 RJ-45 Connector Pinout on page 241
■ TIM514 Connector Pinout on page 242
■ TIM516 Connector Pinout on page 242
■ TIM518 Connector Pinout on page 244
■ TIM521 Connector Pinout on page 245
TGM550 Console Port Pinouts
The console port on a TGM550 Telephony Gateway Module has an RJ-45 connector.
Table 93 on page 240 provides TGM550 RJ-45 console connector pinout information.
An RJ-45 cable is supplied with the TGM550.
