Table 96: TIM510 RJ-45 Connector Pinout (continued)
Signal Pin
No connection 3
R1 - Transmit 4
T1 - Transmit 5
No connection 6
No connection 7
No connection 8
TIM514 Connector Pinout
The TIM514 Telephony Interface Module uses an RJ-11 cable. Table 97 on page 242
describes the TIM514 RJ-11 connector pinout information.
Table 97: TIM514 RJ-11 Connector Pinout
Signal Pin
No connection 1
No connection 2
Ring 3
Tip 4
No connection 5
No connection 6
TIM516 Connector Pinout
The TIM516 Analog Telephony Interface Module uses a B25A unshielded 25–pair
amphenol cable. Table 98 on page 242 describes the TIM516 connector pinout.
Table 98: TIM516 Connector Pinout
Signal Pin
Tip 1
Tip 2
Tip 3
