You can change the default behavior of the
RESET CONFIG
button. For more
information, see the J-series Services Router Basic LAN and WAN Access Configuration
Guide.
Built-In Gigabit Ethernet Ports
Four built-in Gigabit Ethernet ports provide LAN connections over copper interfaces
to hubs, switches, local servers, and workstations. You can also designate an Ethernet
port for management traffic. When configuring one of these ports, you use the
interface name that corresponds to the port’s location. From left to right on the front
panel, the interface names for the ports are
ge-0/0/0
,
ge-0/0/1
,
ge-0/0/2
, and
ge-0/0/3
.
For Gigabit Ethernet port pinout information, see “Gigabit Ethernet uPIM RJ-45
Connector Pinout” on page 233.
Each port has two LEDs, a
TX/RX
LED on the left side and a
LINK
LED on the right
side. Table 10 on page 23 describes the built-in Ethernet port LEDs.
Table 10: Gigabit Ethernet Port LEDs
Description
State
Color
Function
Port is online.
On steadily
Green
LINK
Port is offline.
Off
Unlit
Port is transmitting or receiving data.
Blinking
Green
TX/RX
Port might be online, but it is not receiving data.
Off
Unlit
Console Port
You can use the console port on the chassis front panel to connect to the Routing
Engine through an RJ-45 serial cable. From the chassis console port, you can use the
CLI to configure the router. The console port is configured as data terminal equipment
(DTE) and supports the RS-232 (EIA-232) standard.
For information about securing the chassis console port, see the J-series Services
Router Administration Guide.
For pinout information, see “Chassis Console Port Pinouts” on page 234.
AUX Port
The port labeled
AUX
on the front panel of the J-series Services Router is for future
use and is not activated.
J2320 and J2350 Services Router Hardware Features
■
23
Chapter 2: System Overview
