Page 17
13
SD Slot
A
Card Slot A Status Indicator
B
[SLOT SELECT] Card Slot Selection Button
For switching SDHC cards.
C
SDHC Card Cover
D
Card Slot B Status Indicator
E
[OPEN] SDHC Card Cover Open/Close Knob
Rear
A
Shoulder Belt Mount (x2)
For mounting a shoulder belt (sold separately).
Note:
● Be sure to use a shoulder belt with the strength to
withstand the weight of this camera recorder.
● If the shoulder belt is not properly attached, the camera
recorder may fall and cause injuries.
● Check the instruction manual provided with the shoulder
belt before using.
B
Accessory Connector (Connects to an optional
accessory)
C
Battery Mounting Folder (A Page 21)
The shape is different for GY-HM700CHU/GY-HM700U and
GY-HM700CHE/GY-HM700E.
* The above is the illustration for GY-HM700CHE/GY-
HM700E.
D
C
E
B
A
A
A
B
C
