Chapter 3 BIOS Configuration
CI5VGM User’s Manual 51
Chipset Features Setup
This Setup menu controls the configuration of the motherboard chipset.
ROM PCI/ISA BIOS
CHIPSET FEATURES SETUP
AWARD SOFTWARE INC.
Bank 0/1 DRAM Timing : SDRAM 8ns CPU Warning Temperature : 66 ° C/151 ° F
Bank 2/3 DRAM Timing : SDRAM 8ns Current System Temp. :
Bank 4/5 DRAM Timing : SDRAM 8ns Current CPU Temp. :
SDRAM Cycle Length : 3 Current CPU Fan Speed :
DRAM Read Pipeline : Enabled Current Chassis Fan Speed :
Sustained 3T Write : Enabled VCORE : VCC3 :
Cache Rd+CPU Wt Pipeline : Disabled +12V : +5V :
Cache Timing : Fast -5V :- -12V :-
Video BIOS Cacheable : Enabled Shutdown Temperature : 75 ° C/167 ° F
System BIOS Cacheable : Disabled
Memory Hole At 15MB-16MB : Disabled
AGP Aperture Size : 64M
Cyrix M2 ADS# delay : Disabled
:
Auto Detect DIMM/PCI Clk : Disabled
Spread Spectrum : Disabled ESC : Quit З И Ж Е : Select Item
F1 : Help PU/PD/+/- : Modify
OnChip USB : Enabled F5 : Old Values (Shift) F2 : Color
USB Keyboard Support : Disabled F6 : Load BIOS Defaults
F7 : Load Setup Defaults
DRAM Timing
The DRAM timing is controlled by the DRAM Timing Registers. The
timing type is dependent on the system design. Slower rates may be
required in some system designs to support loose layouts or slower
memory.
SDRAM Cycle Length
This field sets the length of each SDRAM cycle. By default, this field is
set to 3.
DRAM Read Pipeline
When enabled, this field supports pipelining of DRAM reads.
Sustained 3T Write
This field allows support for PBSRAM sustained 3T writes.
Cache Rd+CPU Wt Pipeline
When enabled, this item allows pipelining of cache reads and CPU
writes.
Cache Timing
This field sets the timing of the cache in the system. The options are fast
and fastest. By default, this field is set to fast.
