Chapter 2 Installations
24 CI5VGM User’s Manual
Connectors on the CI5VGM
The connectors on the CI5VGM allows you to connect external devices
such as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on CI5VGM and their respective
functions.
Connector Locations on the CI5VGM................................25
J1: Floppy Drive Connector ...............................................26
J2: Parallel Port Connector.................................................26
IDE1, IDE2: EIDE Connectors ..........................................27
J3: External ATX Power Connector...................................28
J18: AT Power Connector ..................................................28
J4: Audio I/O Connector (optional)....................................28
J5: USB Connector.............................................................29
J6: COM1 Serial Port .........................................................30
J7: COM2 Serial Port .........................................................30
J8: Front Bezel Connector..................................................31
J9: LCD Panel Connector...................................................33
J14: Chassis Fan Power Connector ....................................34
J22, J23: CPU Fan Power Connectors................................34
J15: IrDA Connector .........................................................34
J16: External Keyboard Connector ....................................34
J17: External Mouse Connector .........................................35
J19: PS/2 Keyboard Connector ..........................................35
J20: PS/2 Mouse Connector ...............................................35
J21: VGA CRT Connector .................................................36
J25: RJ45 Connector ..........................................................36
