Chapter 2 Installations
12 CI5VGM User’s Manual
Memory Installation
The CI5VGM Industrial CPU Card supports three 168-pin DIMM
sockets for a maximum total memory of 384MB. The memory modules
can come in sizes of 16MB, 32MB, 64MB, 128MB in EDO DRAM or
SDRAM type.
In populating the DIMM sockets, DIMM1, DIMM2 or DIMM3 can be
populated first. Refer to the following table on how to configure the
memory.
NOTE: You must install memory modules of the same type, either all
SDRAM or all EDO DRAM.
168Pin DIMM (3.3V) - SDRAM or EDO DRAM
(DIMM3) (DIMM2) (DIMM1) Total Memory
8MB ----- ----- 8MB
16MB ----- ----- 16MB
32MB ----- ----- 32MB
64MB ----- ----- 64MB
128MB ----- ----- 128MB
8MB 8MB ----- 16MB
16MB 8MB ----- 24MB
32MB 8MB ----- 40MB
64MB 8MB ----- 72MB
128MB 8MB ----- 136MB
8MB 8MB 8MB 24MB
16MB 8MB 8MB 32MB
32MB 8MB 8MB 48MB
64MB 8MB 8MB 80MB
128MB 8MB 8MB 144MB
16MB 16MB ----- 32MB
32MB 16MB ----- 48MB
64MB 16MB ----- 80MB
128MB 16MB ----- 144MB
16MB 16MB 8MB 40MB
32MB 16MB 8MB 56MB
64MB 16MB 8MB 88MB
128MB 16MB 8MB 152MB
