IBM CI5VGM Series - Manual (Page 48)

Chapter 3 BIOS Configuration
44 CI5VGM User’s Manual
Standard CMOS Setup
“Standard CMOS Setup” choice allows you to record some basic
hardware configurations in your computer system and set the system
clock and error handling. If the motherboard is already installed in a
working system, you will not need to select this option. You will need to
run the Standard CMOS option, however, if you change your system
hardware configurations, the onboard battery fails, or the configuration
stored in the CMOS memory was lost or damaged.
ROM PCI/ISA BIOS
STANDARD CMOS SETUP
AWARD SOFTWARE, INC.
Date (mm:dd:yy) : Wed, Mar 4 1998
Time (hh:mm:ss) : 00 : 00 : 00
HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE
Primary Master Auto 0 0 0 0 0 0 Auto
Primary Slave Auto 0 0 0 0 0 0 Auto
Secondary Master Auto 0 0 0 0 0 0 Auto
Secondary Slave Auto 0 0 0 0 0 0 Auto
Drive A : 1.44M, 3.5in Base Memory : 640K
Drive B : None Extended Memory : 15360K
Other Memory : 384K
Video : EGA / VGA
Halt On : All Errors Total Memory : 16384K
ESC : Quit З И Ж Е : Select Item PU / PD / + / - : Modify
F1 : Help (Shift) F2 : Change Color
At the bottom of the menu are the control keys for use on this menu. If
you need any help in each item field, you can press the key. It will
display the relevant information to help you. The memory display at the
lower right-hand side of the menu is read-only. It will adjust
automatically according to the memory changed. The following
describes the items of this menu.
Date
The date format is:
Day : Sun to Sat
Month : 1 to 12
Date : 1 to 31
Year : 1994 to 2079
To set the date, highlight the “Date” field and use the PageUp/ PageDown
or +/- keys to set the current time.
