Chapter 8 Ethernet Setup User’s Guide
CI5VGM User’s Manual 125
Running Diagnostics
The CI5VGM comes with a diskette containing the diagnostic software
supporting the Intel 82558B Ethernet controller. Follow the steps below
to use the Setup Utility.
1. Run the file
SETUP.EXE typing a:\setup in the DOS prompt,
assuming your floppy disk drive is drive A. Upon doing so, the
system starts the Setup Utility and shows the following screen.
8255x-based PCI EtherExpress™ adapter Setup V4.16
Main Menu
Automatic setup
View adapter configuration
Test adapter
Install network drivers
View Help files
Exit Setup
Choose AUTOMATIC SETUP to view the adapter ’s configuration, make sure it
works properly, and install the software needed to connect to your network.
Help = F1 Exit = Esc Select =
↑↓
Action =
↵
2. Selecting View adapter configuration will show the following.
8255x-based PCI EtherExpress™ adapter Setup V4.16
View adapter configuration
Adapter type:…………………..
Adapter part number:………….
Network address:………………
Interrupt:………………………..
Bus:……………………………..
Slot:……………………………..
Device:………………………….
Network speed:………………..
Physical layer device:…………
Duplex:………………………….
Adapter capabilities:
100BaseTX, full or half duplex.
10BaseT, full or half duplex.
Press Enter to continue
Help = F1 Previous = Esc Continue = Enter PCI Advanced = F5
