Mobile Intel ® 915GME Express Chipset —Hardware Reference
Mobile Intel ® 915GME Express Chipset
Development Kit User’s Manual April 2007
50 Order Number: 317230-001US
4.6.2.7 Fan Connectors
Table 18. SATA Port 2 Power Connector Pinout (J6H3)
Pin Signal
1, 2 +3.3 V
3, 4 +5 V
5 +12 V
6, 7, 8, 9, 10 GND
Table 19. SATA Port 0 Mobile Drive Connector Pinout (J8J3)
Pin Signal
2 TX
3 TX#
5 RX
6 RX#
8, 9, 10 +3.3 V
14, 15, 16, 18 +5 V
20, 21, 22 +12 V
1, 4, 7, 11 GND
12, 13, 17, 19 GND
Table 20. Fan Connectors (J3F4 and J3B1)
Pin Signal
1 +5V
2 GND
