Theory of Operation—Mobile Intel ® 915GME Express Chipset
+5VS_PHASE2 (CPU Core) R3B3.2
+5VS_VTTMCH R4V1.2
Battery Voltage +VBAT U4F2.14
+VCC_LVDSBKLT R6F9.1
VBAT_VTTVR R4G2.2
VDC_VDDQVR R5B5.1
+VBAT_MCHVR R4G1.2
Batter Voltage Always +VBATA R5J1.2
+V12_ATX R5J1.1
Battery Voltage Switched +VBATS Q6B2.5-8
+V12S_PEG R6B5.1
VBATS_L R5G1.2
+V12S_PCISLOT0 R8B11.2
+V12S_PCISLOT1 R7B19.2
+V12S_PCISLOT2 R8C6.2
+V12S_SATA_P2 R7H12.2
+12VS_PATA R4X4.2
+VCC_GMCH_CORE R4T2.2
+VCC_GMCH R4T2.1
+VCCP R3T1.2
+VCCP_GMCH R4T1.1
+VCCP_VCCPCPU R6W7.1
-12 -V12a R4Y2.2
-V12A_ATX R4Y2.1
Battery Charger +VCHRGR (0.025Ω) R1H6.2
Table 6. Mobile Intel ® 915GME Express Chipset Voltage Rails (Sheet 4 of 4)
Voltage Groups Voltage Rail
Reference
Designator
