Mobile Intel

®

915GME Express Chipset

April 2007

Development Kit User’s Manual

Order Number: 317230-001US

23

Theory of Operation—Mobile Intel

®

915GME Express Chipset

Note:

Memory that utilizes 128 MBit technology is not supported by the GMCH and is not

supported on the Mobile Intel

®

915GME Express Chipset .

Note:

The SODIMM connectors are on the back side of the board.

Caution:

Standby voltage is applied to the SODIMM sockets when the system is in the S3 state.

Therefore, do not insert or remove SODIMMs unless the system is unplugged.

3.4.1.2

DMI

The Mobile Intel

®

915GME Express Chipset GMCH’s Direct Media Interface (DMI)

provides high-speed bi-directional chip-to-chip interconnect for communication with

the ICH6-M.

3.4.1.3

Advanced Graphics and Display Interface

The reference board has five options for displaying video, VGA, LVDS, SDVO, or PCI

Express Graphics. SDVO (ADD2-R) and PCI Express Graphics are multiplexed on the

same pins within the Mobile Intel

®

915GME Express Chipset . The Mobile Intel

®

915GME Express Chipset contains one SDVO/PCI Express Graphics Slot (J6C1) for a

PCI Express compatible graphics card or an SDVO compatible graphics card, one LVDS

connector (J5F1) and one 15-pin VGA connector (J2A1B).

3.4.2

ICH6-M

The ICH6-M is a highly integrated multifunctional I/O controller hub that provides the

interface to the system peripherals and integrates many of the functions needed in

today’s PC platforms. The following sections describe the reference board

implementation of the ICH6-M features, which are listed below:

• Two PCI Express (x1) connectors
• Two PCI connectors
• LPC interface
• Wake-On-LAN support
• System management
• ACPI* 2.0 compliant
• Real Time Clock
• 609 mBGA package
• Two SATA drive connectors
• One IDE connector
• Eight Universal Serial Bus (USB) 2.0 ports (five ports provided on rear-panel, two

provided via front-panel header (J6H2) and one at the PCI Express docking

connector.)

• Integrated 10/100 MAC

3.4.2.1

PCI Express Slots

The reference board has two PCI Express slots for add-in cards. The PCI Express

interface is compliant to the PCI Express Rev. 01a Specification.

3.4.2.2

PCI Slots

The reference board has two x1 PCI slots for add-in cards. The PCI bus is compliant to

the PCI Rev. 2.3 Specification at 33 MHz.
