Mobile Intel ® 915GME Express Chipset
April 2007 Development Kit User’s Manual
Order Number: 317230-001US 37
Hardware Reference—Mobile Intel ® 915GME Express Chipset
4.3 Configuration Settings
Note: Do not move jumpers with the power on. Always turn off the power and unplug the
power cord from the computer before changing jumper settings. Failure to do so may
cause damage to the board.
Figure 4 shows the location of the configuration jumpers and switches.
Table 8 summarizes the supported jumpers and switches and gives their default and
optional settings.
Table 9 summarizes the unsupported jumpers and switches and gives their default
position. The unsupported jumpers must remain in their default position or the
operation of the platform is unpredictable. The Mobile Intel ® 915GME Express Chipset
board is shipped with the jumpers and switches shunted in the default locations.
Figure 4. Configuration Jumper and Switch Locations
B4170-02
J7A2
J7B1
J6E1
J3B2
J3B3
J6B1
J7E3
J8E1
J8E2
J8F1
J7E1
J7E2
J7A3
J9H1
J8H1
J8H2
J9J3
J9J5
SW4A1
J9J6
J8G1
J9J8
J9J7
J7J3
J9J1
J9J2
J7E4
J7C3
J7J1
J5J1
J6H1
J5G1
J5G2
J3F3 J3F1
J6G2
J2J2
J2H1
J1F2
J3C1
J1E3
J1E2
