Mobile Intel ® 915GME Express Chipset
April 2007 Development Kit User’s Manual
Order Number: 317230-001US 15
Getting Started—Mobile Intel ® 915GME Express Chipset
• Two SATA and one IDE (40 pin) Hard Drive interface
• Two PCI 2.3 compliant desktop slots
• 82802AC8 Firmware Hub (FWH)
• 82562EZ 10/100 Mbps Platform LAN Connect (PLC)
• Two x1 PCI Express slots.
Note: There are actually three x1 PCI Express slots but slot 2 was used for validation
purposes. Only slots 0 and 1 are supported.
Clocking
• CK-410M and CK-SSCD
• Battery-backed real time clock
Connector Interface Summary
• One x16 PCI Express Video Interface, doubles as an ADD2-R connector to provide
access to dual SDVO ports if PCI Express is unused
• Two SATA ports
• One Ultra ATA (33/66/100/133) IDE connector supporting up to two IDE devices
• Eight Universal Serial Bus (USB) 2.0 ports (Five ports provided on rear-panel, two
provided via front-panel header (J6H2), and one at the PCI Express docking
connector.)
• Two PCI 2.3 compliant 33 MHz interface connectors
• PS/2-style keyboard and PS/2 mouse (6-pin mini-DIN) connectors
• Standard S-Video connector at back panel interface (not functional)
• LVDS connector on top of circuit board near GMCH
• One VGA connector provides access to integrated graphics
• One LAN connector providing 10/100 connectivity from Intel 82562EZ 10/100 Mbit
PLC
• One 9-pin serial port connector.
• One IrDA port
• Two PCI Express slots (x1)
• Two SODIMM connectors on rear side of circuit board
Debug Features
• Extended Debug Port (XDP) connector
• On-board Port 80h display
Miscellaneous Features
• Configurable for ATX 1.1 Power Supply in desktop mode or AC Mobile Brick/Battery
Pack for Mobile Mode
• ATX Form Factor eight layer PCB
• AMI* system BIOS
• Built-in Wake On LAN (WOL) header
• Three built-in fan power connectors: Rear Chassis Fan, CPU Fan, Front Chassis Fan
• Power/Reset buttons
• CMOS clear jumper
