Mobile Intel ® 915GME Express Chipset
April 2007 Development Kit User’s Manual
Order Number: 317230-001US 49
Hardware Reference—Mobile Intel ® 915GME Express Chipset
4.6.2.5 IDE Connector
4.6.2.6 SATA Pinout
Table 16. IDE Connector (J7J2)
Pin Signal Pin Signal
1 Reset IDE 2 Ground
3 Host Data 7 4 Host Data 8
5 Host Data 6 6 Host Data 9
7 Host Data 5 8 Host Data 10
9 Host Data 4 10 Host Data 11
11 Host Data 3 12 Host Data 12
13 Host Data 2 14 Host Data 13
15 Host Data 1 16 Host Data 14
17 Host Data 0 18 Host Data 15
19 Ground 20 Key
21 DRQ3 22 Ground
23 I/O Write 24 Ground
25 I/O Read 26 Ground
27 I/O Ch Ready 28 CSEL
29 DACK 3 30 Ground
31 IRQ 14 32 NC
33 Address 1 34 DATA Detect
35 Address 0 36 Address 2
37 Chip Select 0 38 Chip Select 1
39 Activity 40 Ground
Table 17. SATA Pinout (J7H1)
Pin Signal
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
