Intel 915GME - Manual (Page 47)

Mobile Intel ® 915GME Express Chipset
April 2007 Development Kit User’s Manual
Order Number: 317230-001US 47
Hardware Reference—Mobile Intel ® 915GME Express Chipset
4.6.2.4 PCI Express (x1)
The three PCI Express x1 connectors allow the use of any industry standard PCI
Express device. The pin configuration of the connectors is given below.
51 GND N/C
52 N/C GND
53 N/C GND
54 GND N/C
55 GND N/C
56 N/C GND
57 N/C GND
58 GND N/C
59 GND N/C
60 N/C GND
61 N/C GND
62 GND N/C
63 GND N/C
64 N/C GND
65 N/C GND
66 GND N/C
67 GND N/C
68 N/C GND
69 N/C GND
70 GND N/C
71 GND N/C
72 N/C GND
73 N/C GND
74 GND N/C
75 GND N/C
76 N/C GND
77 N/C GND
78 GND N/C
79 GND N/C
80 N/C GND
81 N/C N/C
82 GND Reserved
Table 14. ADD2 Slot (J6C1) (Sheet 3 of 3)
Pin
Number
A B
