4.4
Power On and Reset Buttons
The Mobile Intel
®
915GME Express Chipset board has two push buttons, POWER and
RESET. The POWER button releases power to the entire board, causing the board to
boot. The RESET button will force all systems to warm reset. The two buttons are
located near the CPU close to the edge of the board. The POWER button is located at
SW1C2 and the RESET button is located at SW1C1.
Figure 5.
Mobile Intel
®
915GME Express Chipset Power On and Reset Buttons
B4728-01
Reset
Power Up
