v If yes:
a. An SRN was obtained from diagnostics.
b. Use the following SRN table (Table 1-9) to continue service.
c. After using Table 1-9, go to “Step 0620-012” on page 1-26.
v If no:
a. The diagnostics did not detect a problem, therefore the problem is in SP Switch.
b. Go to “Step 0620-041” on page 1-35.
Table 1-9. Service Request Number (SRN) table for SP Switch adapters
Service Request Number
SRN
source Failing component(s) Description
D 762-100
through
762-199SPS adapter
software
system or I/O planar Problem detected with device or
device data corrupted. You may
need to reinstall “ssp.css” code.
762-200
through
762-299 D external clock
SPS adapter
(wrap plug) Problem detected with external
clock.
762-2A0
through
762-2A9 D SPS adapter Problem detected with internal
clock.
762-300
through
762-399 D SPS adapter
system or I/O planar Problem detected with POS
registers.
762-400
through
762-499 D SPS adapter
software TBIC test failed.
762-500
through
762-599 D SPS adapter SRAM test failed.
762-600
through
762-699 D SPS adapter Microprocessor test failed.
762-700
through
762-799 D SPS adapter Interrupt test failed.
762-800
through
762-899 D SPS adapter FIFO test failed.
762-900
through
762-999 D SPS adapter
I/O planar
data cable DMA engine test failed.
762-Ax3
(See note) D SPS adapter
(terminator) Card wrap test failed.
762-Ax4
(See note) D SPS data cable
(wrap plug) Cable wrap test failed.
763-1xx
(See note) D SPS MX adapter
software
system or I/O planar Problem detected with a device
or device data corrupted.
Note: You may need to reinstall
ssp.css software.
